维安(WAYON)是电路保护元器件及功率半导体提供商。WAYON始终坚持“以客户为导向，以技术为本，坚持艰苦奋斗”的核心价值观。致力于通过技术创新引领市场，努力成为全球电路保护元器件及功率半导体的领先品牌。
| Part No. | Rated current(A) | Rated voltage(V)DC | Operating Voltage(V) | Fuse DCR(mΩ) | Heater DCR(Ω) | Breaking(A) | Applicable Cells in series(cell) | Data sheet |
|---|
| WPF45A14K-11P | 45 | 80 | 72.0-92.0 | 0.5-2.5 | // | 120 | 24 LFP |  |
| WPF45A14K-7P | 45 | 80 | 50.0-74.0 | 0.5-2.5 | // | 120 | 20 LFP | |
| WPF45A14K-3P | 45 | 80 | 35.0-62.0 | 0.5-2.5 | // | 120 | 16 LFP | |
| WPF45A14K-2P | 45 | 80 | 40.0-54.0 | 0.5-2.5 | // | 120 | 15 LFP | |
| WPF45A14K-7 | 45 | 80 | 70.0-90.0 | 0.5-2.5 | // | 120 | 20 | |
| WPF45A14K-4 | 45 | 80 | 59.5-76.0 | 0.5-2.5 | // | 120 | 17 | |
| WPF45A14K | 45 | 80 | 47.2-62.0 | 0.7-2.5 | // | 120 | 13-14 | |
| WPF45A10K | 45 | 80 | 33.0-47.0 | 0.5-2.5 | // | 120 | 9-10 | |
| WPF45A8K | 45 | 80 | 26.7-37.6 | 0.5-2.5 | // | 120 | 8.0 | |
| WPF45A7K | 45 | 80 | 22.3-31.5 | 0.5-2.5 | // | 120 | 6-7 | |
| WPF45A5K-2 | 45 | 80 | 19.8-27.0 | 0.5-2.5 | // | 120 | 6.0 | |
| WPF45A5K | 45 | 80 | 16.7-23.5 | 0.5-2.5 | // | 120 | 5.0 | |
| WPF45A4K | 45 | 80 | 13.0-18.4 | 0.5-2.5 | // | 120 | 4.0 | |
| WPF45A3K | 45 | 80 | 9.8-13.5 | 0.5-2.5 | // | 120 | 3.0 | |
| WPF30A10K-3 | 30 | 62 | 42.0-74.8 | 1-2.5 | // | 80 | 15-17 | |
| WPF30A10K-4 | 30 | 62 | 36.2-58.5 | 1-2.5 | // | 80 | 13 | |
| WPF30A10K-2 | 30 | 62 | 33.6-54.0 | 1-2.5 | // | 80 | 12 | |
| WPF30A10K | 30 | 62 | 28.0-62.0 | 1-2.5 | // | 80 | 10-14 | |
| WPF30A9K-2 | 30 | 62 | 26.4-36.0 | 1-2.5 | // | 80 | 8.0 | |
| WPF30A7K | 30 | 62 | 20.2-31.5 | 1-2.5 | // | 80 | 6-7 | |
| WPF30A4K | 30 | 62 | 10.5-23.5 | 1-2.5 | // | 80 | 4-5 | |
| WPF30A3K | 30 | 62 | 8.4-13.2 | 1-2.5 | // | 80 | 3.0 | |
| WPF30A2K | 30 | 62 | 5.6-9.0 | 1-2.5 | // | 80 | 2.0 | |
| WPF30A1K | 30 | 62 | 4.0-6.6 | 1-2.5 | // | 80 | 1.0 | |
